We are professional Car Rear View Systems and Car Rear View Cameras factory, support DIY service. Choose you interesting monitors and camaras from our website, we can match them to be a completed system for you.

This following trailer system is mainly used for trucks, trailers, buses and other heavy duty vehicles surveillance, back up or side view. Cameras can be installed on the front, back, both sides or even inside the bus as you need. Automatically switch to display the full picture while parking, turnning left or right.



 Specification:



           Color CCD Rear View Camera (Model: RC-502)

◆ Waterproof resistance: IP 69

◆ IR LED light:18pcs blue LED

◆ Night Vision available ,day/night for automatic adjustment

◆ Image Pick-up Device : 1/3  Sharp CCD ( Sony Optional )

◆ Audio fuction : optional

           ◆ The lens focal length and angle: 3.6mm 92° / 2.8mm 120° / 2.2mm 150° ( Optional )

◆ Video Output : 1.0Vp-p 75Ω , Negative

◆ Operation Temperature : -20℃- +60℃  RH 95% Max

◆ Power Supply : DC12V±10%,250mA

◆ Housing Colours : Black

               5" COLOR TFT-LCD Color Digital  Monitor (Model:RM-501)

      ◆ Housing Colors : Black,silver (Optional)
              ◆ Products: LCD Color Monitor

◆ Display Device : Color TFT- LCD

◆ Screen Size : 5 Inch

◆ Aspect Ratio :16:9

◆ Resolution : 640(H) x RGB x 480(V) (Digital Monitor)

◆ Audio Output : 0.5W(Max)

◆ Video Input : 1Vp-p two Way

  ◆TV System: PAL/NTSC

 ◆ Mirror function: YES

 ◆ Loudspeaker : one 4.0cm round loudspeaker

 ◆Eight Languages OSD Menu: Chinese, English, Japanese, French, Spanish, Russian, German and Arabic

  ◆ Power supply : 12~24V

 ◆ Power Consumption : about 8W

 ◆ Outer Dimension : W 163mm x H 125mm x T 30.5mm

   ◆ Weight ; about 330g (include headrest shell)
